Final Checks Before Accepting a Pergola Installation
Pergola handover
Treat the handover as a recorded comparison between what was agreed and what is installed, followed by a demonstration of anything that moves or controls water. A tidy appearance alone cannot confirm that the roof operates correctly, drainage reaches its intended outlet or all ordered items have been supplied. Use the walkthrough to identify completed work, questions and follow-up, then keep the notes and photographs with your project documents.
Gather the agreed scope and drawings
Bring together the latest approved drawing or plan, final order or quote, installation scope, any specification schedule and the record of agreed variations. Mark the revision or date on each so you and the installer are working from the same version. Check that the project documents identify the model, dimensions, orientation and options you agreed to buy. A catalogue page can help identify a model—for example, the Bloomcabin Bioclimatic Pergola page—but it does not replace site-specific drawings or confirm your inclusions. If an email or project-portal approval changed the original scope, save it with the final documents and note which drawing or order line it changed.
Set up a simple handover record with the site address, date, people present and the drawing revision used for the walkthrough. Give each area its own line: operation, drainage, visible condition, supplied items and documents. For every observation, note what you saw or tested, where it is, and a photo reference if useful. Mark an item as demonstrated, outstanding or not checked; don’t treat an inaccessible connection or untested drainage route as complete just because it could not be seen. Ask who will provide any missing information and keep a copy of the finished record with your project correspondence.
Compare the installed position with the plan
Walk around the structure with the approved plan and compare its visible position, footprint, post locations and orientation with what was agreed. Check its relationship to the house, paving, doors, paths and other features shown on the drawing. Use the project dimensions rather than estimating from a product image or catalogue page. For a design attached to a building, compare the visible position at that interface with the approved details; for a freestanding design, check the post layout against the plan. If your order names the model shown in the Bloomcabin Pergola listing, use that name alongside the drawing reference in your installation record.
Check clearances that mattered to the agreed layout: doors and windows should still open as planned, routes should remain usable, and specified access to controls or service points should not be blocked. If you take a measurement, note the reference points and compare like with like against the drawing; don’t invent your own tolerance. Photograph an overall view as well as any position that appears different from the plan. If a dimension, post position or wall junction does not match, ask the installer to compare it with the approved details and explain whether a drawing was revised. Record the location precisely rather than writing only that the pergola appears incorrectly positioned.
Watch the roof operate as specified
If the agreed configuration has an opening, tilting or otherwise moving roof, ask the installer to demonstrate its normal range of movement using the supplied controls or method. Observe from a clear, safe position as it starts, stops and reaches the position shown in the instructions. Note scraping, repeated knocking, hesitation, panels that stop short or a visible mismatch at the end of movement. Don’t climb onto the structure, reach between moving parts or force a mechanism that does not respond. For a unit recorded as Bloomcabin Bioclimatic Pergola, check the approved configuration rather than assuming the model name alone describes the operation agreed for your job.
Ask the installer to repeat a demonstration if you could not see a clear start and end position, but follow the manual rather than operating the mechanism repeatedly yourself. A fixed-roof design does not need to move, so ask which checks are relevant to that configuration instead of treating a lack of movement as a fault. If the roof pauses, makes an unexpected sound or responds inconsistently, stop the demonstration and ask for an assessment before routine use. Record what was shown, what could not be tested and any explanation given. This is more useful later than a general note saying that the roof works.
Test the controls and included accessories
Try each supplied control with the installer, one at a time. If the design has more than one control point, ask which roof section or accessory each one operates. Check that the switch, remote or other control listed for your job is present and responds as demonstrated. Don’t assume an item is included because it appears in a sales image or belongs to the same product range; use the agreed scope to confirm what should be on site. Ask how normal movement is stopped and what to do if a control fails. Don’t open covers, alter wiring or try to repair a control during the handover.
If a sensor, light, screen or other accessory is listed, ask the installer to demonstrate its normal operation and leave any separate instructions. Confirm that any remotes, keys or other small parts specified for your job have been handed over, and note where you have stored them. If the project documents name the Bloomcabin Wall-Mounted Pergola, use that model name in your handover record; the listing identifies the model, while your approved order defines the supplied accessories. Don’t test electrical items beyond the installer’s demonstration, particularly if something is loose or visibly damaged. Refer a control or electrical concern to the appropriate qualified person rather than attempting a repair.
Trace the roof drainage to its outlet
Ask the installer to explain the intended route for rainwater from the roof through any gutters or channels specified for your installation and on to the outlet or discharge point. Follow the route from ground level where possible, checking that visible sections appear connected and that the water is directed as shown in the approved arrangement. If a demonstration is suitable, let the installer choose the method and carry it out. Don’t block an outlet, climb to inspect a gutter or direct a hose at a junction without guidance. For an installation identified on your order as the model on the product page for Bloomcabin’s wall-mounted pergola, record the site-specific drainage route and outlet location alongside the model name.
During an approved demonstration, watch for water escaping at joints, collecting somewhere unintended, running towards a building opening or discharging differently from the plan. Ask where any overflow goes and whether the surface below is meant to carry water away; don’t assume the paving has a particular fall. A dry-weather visual check can show whether an outlet is connected, but not how the arrangement behaves in rain. If part of the route is concealed or not obvious, ask the installer to identify it on an as-installed drawing or in a photo. Record the route explained and any leak, splash or pooling observed, including where it occurred.
Review visible connections and surrounding surfaces
Inspect only parts that are safely visible from the ground. Look for a damaged cover, an exposed component that differs from the drawing, gaps at a visible wall junction, or cracked or disturbed paving around a post base. These are observations for the installer to assess, not a home engineering test. Don’t climb, lean heavily on the frame, tighten fasteners or try to load the roof. If a base, bracket or connection is hidden, ask the installer to show the relevant detail in the approved or as-built information and explain what was completed before it was covered.
Note any movement observed during the normal demonstration, a post that appears out of position, a new crack or a gap where the approved detail shows a connection. Photograph the exact corner or side and ask the installer to inspect it before treating the work as complete. Don’t judge from appearance alone whether a fixing, slab or adjoining wall is structurally suitable; that assessment needs the project information and an appropriately qualified person. If your order identifies the model shown on the Bloomcabin Pergola product page, use the same model name when reporting the concern. If it cannot be resolved during the walkthrough, record who will assess it and what information or access they need.
Inspect the finish in good light
Review visible surfaces in good natural light, including corners, edges, trim and areas that will be difficult to see once furniture or planting is back in place. Look for scratches, dents, chips, stains, residue, uneven-looking joints or damage from access and assembly. Compare the finish with the selection recorded in your order, not just a screen image. Check the perimeter and underside where they can be seen safely; use a torch for a shaded junction, but don’t dismantle parts or remove protective layers unless the installer says they are ready to come off. Photograph each mark before cleaning or touching it.
Inspect adjoining areas too: paving, walls, doors, drainage covers and garden edges that were within the agreed work zone. Record a scuff, crack, sealant spill, leftover packaging or incomplete make-good separately from a finish issue, since responsibility may differ. Ask before applying cleaner, polish, paint or touch-up material; an unsuitable product could make a mark harder to assess or repair. For each item, note the location and whether it needs attention from the installer, another trade or clarification of the agreed scope. A specific description and photograph are more useful than a general note such as finish not right.
Match supplied items to the final order
Reconcile the installed and supplied items against the final order, variation notes and installation scope, not just the original quote. Check each named frame or roof component, trim, side element, control, remote, sensor, light or other accessory only where it appears in the agreed package. Compare quantities and locations with the drawing, then mark each item as present, installed, demonstrated or outstanding. For a job recorded as Bloomcabin’s Wall-Mounted Pergola, keep the model name consistent in your inventory and follow-up notes; the project order defines what was included.
Ask the installer to identify any spare parts, keys, fixings or leftover components that belong to you before disposing of anything left on site. Confirm who removes packaging and construction debris if the documents do not make that clear. Look at joints, covers and trim where one element meets another, but ask the installer to explain an unfamiliar gap rather than filling it yourself. If a named part is absent, damaged or not fitted, record its name as it appears on the order, its intended location and the agreed action. This gives both parties a clearer reference than a general statement that an accessory is missing.
Collect manuals and maintenance information
Ask for the manual and maintenance instructions that match the installed model and any supplied control or accessory. Where a model identifier is provided, check it against the name on your order; a manual for a similar-looking product may not describe the controls fitted to your pergola. For an order naming the Bloomcabin Bioclimatic Pergola, check that the supplied documents identify the same model and cover the configuration installed. Request a revised or marked-up drawing if the layout changed, and any information the installer has promised about settings, parts or service. Save digital files somewhere you can find them and keep paper copies together.
Have the installer explain the routine actions described in the written guidance: how to use the controls, which parts need regular visual attention, what cleaning methods are permitted and when to stop and ask for service. Don’t rely on a verbal explanation alone for maintenance or on a generic cleaning tip from an online forum. Collect warranty information and the correct service contact where these form part of your handover documents, and note any product identification or serial details provided. Ask whether the installer changed a setting or left a configuration note. Record it without altering it yourself, so you know what was handed over and where to find the relevant instructions later.
Record outstanding work before signing
Turn each unresolved issue into a specific action before the installer leaves: state the location, what you observed, the agreed remedy or assessment, the person responsible and the date for an update or return visit. Attach a photo and refer to the relevant drawing or order line where that helps. Separate incomplete work from a question that needs investigation, and mark anything not tested with the reason. If a control fails, water leaks, a component is damaged or movement concerns you, avoid operating the affected part until the installer or relevant qualified person has assessed it. Update the item when the action is complete and record how the result was checked.
Read the completion or acceptance form before signing and make sure it reflects what happened on site, including outstanding items and agreed follow-up. If there is no space for exceptions, ask how to attach the outstanding work list and make sure you receive a copy of both. The effect of a signature depends on the wording and your project documents, so ask the responsible party or an independent adviser if it is unclear. If a consent process or insurer condition applied, ask the responsible designer or installer which completion records are relevant and confirm local requirements with the appropriate authority or qualified adviser. This checklist cannot decide whether a particular New Zealand installation needed consent. Keep the signed record, drawings, manuals, photographs and follow-up correspondence together.
Pergola handover FAQs
Should I wait for rain to check the pergola’s drainage?
No. Ask the installer to explain the intended water route and, if appropriate, demonstrate it using a suitable method. Don’t create your own test by blocking an outlet or spraying into a junction. If the route could not be demonstrated, record it as not checked rather than treating a dry-weather inspection as proof.
What should I do if I find a cosmetic mark?
Photograph it in good light, note its exact location and compare it with the finish agreed in your project documents. Ask the installer how it will be assessed or remedied before trying to clean or touch it up yourself. Put the agreed response and any follow-up date on your handover record.
Can I test a moving roof after the installer has left?
Use it only as described in the supplied instructions and demonstrated at handover. Don’t force a mechanism, climb onto the structure or reach between moving parts. If it doesn’t respond as expected, stop and ask the installer or the appropriate service professional to investigate.
Which documents should I have at handover?
Ask for the manuals and maintenance guidance for the installed model and supplied controls or accessories, plus any revised or as-installed drawings. Keep the final order and variations, product identification details, and relevant service or warranty information together. Completion records that apply to your project should be confirmed with the responsible professional.
Can I sign off if some work is still outstanding?
There is no universal answer: read the wording of the form and your project documents. If anything remains, ask how to attach a written list of the work, who is responsible and when it will be followed up. Don’t sign a record that doesn’t reflect what happened on site, and get a copy of the final paperwork.
A useful handover record is specific enough for someone who was not at the walkthrough to understand what was demonstrated and what remains to be done. Keep the approved drawings, operation notes, drainage observations, photos, manuals and dated action list together. When follow-up work is complete, update the relevant line and record how it was checked. That gives you a practical reference for operating and maintaining the pergola after the installer has left.
